Brand Name : | OiD |
Model Number : | OiD651533-280 |
Certification : | RoHS compliant UL1642 certified IEC/EN61960 compliant GB/T 18287-2013 compliant |
Price : | $0.5 ~ $100.0 / pcs |
Delivery Time : | 3 ~ 7 days for storage |
Payment Terms : | TT,L/C,Western Union |
OiD651533-280 Lithium Polymer Battery 3.7V 280mAh 1C Discharge 500 Cycles
Product Name
OiD651533-280 Lithium Polymer Battery
Advantages
Specifications
Parameter | Value |
Nominal Voltage | 3.7V |
Minimum Capacity | 275mAh (0.2C discharge) |
Typical Capacity | 280mAh (0.2C discharge) |
Charging Voltage | 4.2V |
Discharging Cut-off Voltage | 3.0V |
Standard Charging | 0.2C/4.2V |
Max Charging | 1.0C/4.2V |
Standard Discharging | 0.2C/3.0V |
Max Discharging | 1.0C/3.0V |
Weight | Approx. 5.0g |
Shipment Voltage | 3.90±0.05V |
Battery Pack Impedance | ≤300mΩ |
Terminal Type | Tab |
Terminal Material | Nickel |
Cycle Life
Condition | Cycles | Capacity Retention |
0.2C Charge/Discharge at 23±2℃ | 500 | ≥80% |
Discharge Curve
Operating Temperature Range
Condition | Temperature Range |
Charging | 0℃ ~ 45℃ |
Max Charging Current (0℃ ~ 10℃) | 0.2C max |
Max Charging Current (10℃ ~ 20℃) | 0.5C max |
Max Charging Current (20℃ ~ 45℃) | 1.0C max |
Discharging | -20℃ ~ 60℃ |
Max Discharging Current (-20℃ ~ 0℃) | 0.2C max |
Max Discharging Current (0℃ ~ 25℃) | 0.5C max |
Max Discharging Current (25℃ ~ 60℃) | 1.0C max |
Storage (50% SOC) | -10℃ ~ 25℃ (12 months, ≥85%) |
Storage (50% SOC) | -10℃ ~ 45℃ (6 months, ≥85%) |
Storage (50% SOC) | -10℃ ~ 55℃ (1 month, ≥90%) |
Certifications
Key Features
Applications
Usage Warnings & Precautions
Storage Guidelines
Warranty & Disclaimer
![]() |
