SNR32700L35 Sodium Ion Battery 3.0V 3.5Ah High Pulse Discharge 10000 Cycle Life
Product Name:
SNR32700L35 Rechargeable Sodium Ion Battery
Advantages:
Specifications:
Parameter | Specification |
Model | SNR32700L35 |
Nominal Voltage | 3.0V |
Typical Capacity | 3.5Ah |
Minimum Capacity | 3.45Ah |
Operating Voltage Range | 1.5V ~ 3.9V |
AC Impedance (1kHz) | ≤5mΩ |
Standard Charge Current | 0.5C |
Max Continuous Charge Current | 3C (15°C ~ 55°C) |
Standard Discharge Current | 0.2C |
Max Continuous Discharge Current | 10C |
Max Pulse Discharge Current | 30C (for ≥10 seconds) |
Weight | 120±3g |
Dimensions | Diameter: 32.4±0.1mm, Height: 71±0.5mm |
Shipping Status | 20%~70% SOC |
Cycle Life:
Cycle Type | Cycle Life |
0.5C Charge / 1C Discharge | 1000 cycles ≥70% capacity retention |
1C Charge / 25C Pulse Discharge | 10,000 cycles ≥90% capacity retention, 30,000 cycles ≥80% capacity retention |
Operating Temperature Range:
Operation | Temperature Range |
Charging | -10°C ≤ T < 0°C (0.1C CC to 90% SOC) |
0°C < T ≤ 15°C (0.2C CC to 100% SOC) | |
15°C < T ≤ 55°C (3.0C CC to 100% SOC) | |
Discharging | -40°C ≤ T < -20°C (≤3C) |
-20°C ≤ T < 0°C (≤5C) | |
0°C ≤ T < 80°C (≤10C) | |
Storage | 1 month: -20°C ~ 45°C |
3 months: 0°C ~ 45°C | |
1 year: 0°C ~ 25°C |
