OiDA988188-30000-5C-22.2 Drone Battery 22.2V 30000mAh 60A Continuous Discharge 200 Cycles

Product Name

OiDA988188-30000-5C-22.2 Drone Battery

Advantages

• High energy density for extended drone flight time.
• Optimized for high-current discharge (5C rate).
• Lightweight design with robust performance.

Specifications

Cycle Life

Discharge Curve

(Note: Curve data not provided; refer to manufacturer for detailed graphs.)

Operating Temperature Range

Certifications

Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).

Key Features

• 5C discharge capability for high-power drone applications.
• 6S1P configuration with balanced voltage output.
• Lightweight design (2.48kg) for improved payload efficiency.

Applications

• Industrial and commercial drones.
• High-performance UAVs.
• Heavy-lift RC models.

Usage Warnings & Precautions

• Do not exceed 25.5V (4.25V/cell) during charging.
• Avoid short circuits; use insulated tools for assembly.
• Do not discharge below 17.1V (2.85V/cell) to prevent damage.
• Soldering: ≤350°C for ≤3s, max 5 times per terminal.

Storage Guidelines

• Long-term (3+ months): Store at 21.6–23.4V (-10–45°C, 65±20% RH).
• Activation: Every 3 months with 0.2C charge/discharge cycle.

Warranty & Disclaimer

• 12-month warranty from shipment date.
• Void if misused (e.g., over-discharge, improper storage, physical damage).

Usage Warnings & Precautions:

• Avoid overcharging and deep discharging to maintain optimal performance.
• Handle with care to prevent physical damage.
• Do not expose the battery to extreme temperatures or flames.

Storage Guidelines:

• Store in a cool, dry place with a temperature range of 20°C to 25°C for optimal preservation.
• For long-term storage, charge to between 21.6V and 23.4V and store at ambient temperatures between -10°C to 45°C.

Warranty & Disclaimer:

• 12-month limited warranty against manufacturing defects.
• The manufacturer is not responsible for damages resulting from improper handling, storage, or usage outside of the specified conditions.
